The AC 3200 is an active, high-power 8:1 antenna combiner for large multi-channel wireless monitoring systems. the AC3200-II combines up to eight channels for transmission via one antenna, with a broadband design covering 500 - 870 MHz. It significantly reduces intermodulation of wireless monitoring transmitters while keeping backstage clutter to a minimum. Long distances can be covered reliably as the AC 3200 accepts up to 250 mW of input power.

• Active 8-channel 0 dB transmitter combiner with highly constant RF output power over the entire frequency range

• Significant improvement of RF performance for multi-channel systems

• Broadband RF design to cover the UHF frequency range from 500-870 MHz

• Maximum input power of 250 mW

• LEDs on the front show whether a signal is present at the RF input

• Compatible with SR 2050XP IEM, SR 2000XP IEM, SR 300 IEM G3, and legacy EW and 3000 Series monitor transmitters

What's in the Box

• 1 AC 3200-II active transmitter combiner
• 1 NT12-125D in-line power supply
• 3 power cables (US/EU/UK)
• 4 self-adhesive device feet
• 1 instruction manual
