DAS WR Series 800 Watts RMS 15" Compact Arrayable Passive Subwoofer with Direct Exposure (Black)

WR-151S-DX

DAS

Whatsapp for enquiry Email for enquiry






The WR (weather resistant) series expands with a compact subwoofer designed to provide extended range for the WR series full-range cabinets. The WR-151SDX incorporates a single 800 Wrms 15″ loudspeaker. The WR-151SDX offers identical cabinet dimensions as the WR-6415DXW for easy combination in tight packed arrays. Threaded rigging points and optional mounting hardware are available.

The WR-151S offers two exposure ratings: CX (covered exposure) for applications where cabinets are covered or protected, and DX (direct exposure) where cabinets are unprotected and directly exposed to the environment. The CX versions are protected with a thick ISO-flex polyurea coating on the exterior surface. The DX versions augment the protection rating by employing a fiberglass exterior. Stainless steel fittings and mounting hardware are offered on both versions.


Performance
Frequency Range (-10 dB) 45 Hz – 125 Hz
Nominal Impedance Passive: 4 ohms Biamp: 8 ohms
RMS Power Handling 800 W
Peak Power Handling 3200 W
On-axis Sensitivity 1W/1 m 98 dB SPL
Maximum Peak SPL at 1 m 133 dB
Recommended Amplifier PA-1500
Recommended Processor DSP-226
Connectors
Audio Input Connector Covered Barrier Strip Terminals
Audio Output Connector Covered Barrier Strip Terminals
Enclosure
Enclosure Construction Birch Plywood
Enclosure Geometry Rectangular
Rigging M10 Rigging Points
Finish Fiberglass
Color Black
IP Rating IP54
Depth 460 mm (18,1 in)
Dimensions ( H x W x D ) 775 x 465 x 460 mm
30,5 x 18,3 x 18,1 in
Net Weight 33,0 kg ( 72,8 lb )
Components
LF Driver 15SX
