MINKEZ 10 Channel Zones Selector with CAT5

MZS-10ZN

minkez

Whatsapp for enquiry Email for enquiry






FEATURES:

- Built-in 10 zone selectors, which can be expanded to 300 zones. - Work together with remote paging console for paging and control over 10 zones. - Individual zone, group zones, 10 zones and all zones paging through remote paging console. - With memory function when power off, it can realize the restoration after electricity is turned on. - 2 channels 10 zones amplifier inputs (A channel for BGM amplifier and B channel for EMC / paging amplifier), in this way, the other zone's music system will not be interrupted when some zone is selected for paging. - 2 flexible amplifier connections: either 20 amplifiers wiring (10 BGM amps and 10 EMC / paging amps, there must be one of the BGM amp and EMC / paging amp as one channel) and each of the 10 amps severs as one zone or 2 amplifiers wiring (1 BGM amp and 1 EMC / paging amp) and one amplifier divide into 10 zones. - Each zone power capacity is 500 W and the total 10 zones capacity is 5000 W. - 10 zones speaker output terminals. - All zone alarm in (A / B 2 channels) and all zone alarm output (A / B 2 channels). - Two-color zones status indicators accurately indicate music, paging, or alarm status. - MIC 1 - 2 inputs, LINE 1 - 2 inputs and audio output. - 3 levels of input priority from high to low: EMC input, MIC1, remote paging console (equivalent priority with built-in chime). - Built-in chime, chime volume and trigger are provided. - Zone 1 to 10 selector, music / paging switch and all zone selector is equipped with indicators. - Volume control over MIC 1 to 2 is provided. - 2 RJ45 communication ports for paging console or cascade another paging controller. - Dip switch as ID address to be distinguished by the controller or paging console.


Model: MZS-10ZN

Input: MIC1, 2 - 600 Ω, 5mV, unbalanced LINE1, 2 - 10 KΩ, 775 mV, unbalanced Output: 80 dB Frequency Response: MIC - 100 Hz~15 KHz LINE - 30Hz~18 KHz S/N Ratio: MIC Input - 60 dB LINE Input - 80 dB Controls: MIC1, 2 Volume controls, 10 channel selectors, chime button, power switch Indicators: Power LED, 10 paging channel LEDs Power Supply: 100 V ~ 230 V, 50 / 60 Hz & DC 24 V Power Consumption: 40 W Weight: 5.04 kg Dimensions (mm): 484 * 303 * 88 Communication Protocol: RS422 Communication Input: RJ45 Communication Speed: 4800 bps Finish: Panel - aluminium plate, black or golden (optional) Case - steel plate, black
