JBL Professional | CONTROL 321C





JBL Control 300 Series 250 Watts 12" Coaxial Ceiling Speaker with HF Compression Driver

CONTROL 321C

JBL Professional

Whatsapp for enquiry Email for enquiry






The Control 321C has been engineered from the ground up to deliver exceptional next-generation performance in a coaxial point source design ceiling loudspeaker.


Features

  • Consistent 90° broadband pattern control.
  • Components
    • 300 mm (12 in) woofer with Kevlar-reinforced cone with 50 mm (2 in) voice-coil.
    • 25 mm (1 exit) compression driver.
  • Extraordinary clarity for speech and vocals with extended frequency response for music.
  • 250 Watt power handling with high sensitivity provides high SPL capability.
  • Advanced high-slope crossover network for constant coverage and smooth, natural midrange.
  • Clean, contemporary grille and optional backbox available.


Frequency Range (-10dB) 34 Hz – 18 kHz
Power Rating IEC Long-Term System Power Rating: 250 W continuous pink noise (1000 W peak), 2 hrs 200 W continuous pink noise (800 W peak), 100 hrs
Sensitivity 94 dB (1 kHz - 16 kHz)
Frequency Response (±3 dB) 47 Hz – 16 kHz
Coverage Angle 90° conical, constant directivity
Directivity Factor (Q) 8.7 (1k - 16kHz)
Directivity Index (DI) 9.4 dB (1k - 16kHz)
Crossover Network 1.8 kHz, 3rd order (18 dB/oct) high-pass plus conjugate to HF, 2nd order low-pass to LF
Impedance 5.6 ohms
Dimensions (H x W x D) 366 x 366 mm (14.4 x 14.4 in) square baffle x depth from back of baffle of 223 mm (8.8 in)
Maximum SPL (1m) 118 dB (124 dB peak)
Input Connectors Screw locking barrier strip for bare wire
Drivers LF Driver: 300 mm (12 in)
HF Driver: compression driver, 25 mm (1 inch) coil
Color White
Safety Agency Suitable for use in air handling spaces per UL1480, UL2043, NFPA90 & NFPA 70 when installed with UL listed backcan such as JBL MTC-300BB12. S7232/UL Listed, Signaling Speaker. Transformer UL registered per UL1876. In accordance with IEC60849/EN60849.
Backcan formed steel (wood-lined; accessory)
Baffle/Rim Metal, driver pre-mounted to baffle, ported.
Ceiling Cutout Size 378 x 378 mm (14.9 x 14.9 in) (for MTC-300BB12 backcan)
Optional Accessories MTC-300SG12 Grille, square contoured, white. MTC-300BB12 Backbox, 80 liters (3 cubic feet) MTC-300T150 Transformer, 150 W for use with 321C.
Plenum Usage Yes, with accessory backcan
