JBL VTX Series Ground Stackable Dual 18" Ultra Long Throw Subwoofer

VTX-G28

JBL Professional

Whatsapp for enquiry Email for enquiry






VTX series dual 18" subwoofers employ two 2269H 18" transducers featuring Differential Drive technology with two voice coils, two neodymium magnets and extremely high peak-to peak excursion capabilities to deliver extended very low frequency performance.


The VTX G28 is ground stackable only with a practical form factor for convenient stacking and additional enclosure volume plus port tuning that delivers true sub performance down to 22 Hz @ -10 dB.


Features

  • JBL’s patented Differential Drive® technology
  • Crown VRack DSP and Amplification
  • JBL HiQnet Performance Manager™ System


System Type Ground Stack-Only, Cardioid-Arrayable, Dual 18-inch Subwoofer
Frequency Range (-10dB) 22 Hz - 80 Hz (Preset: VTX G28)
Coverage Omnidirectional or Cardioid
Maximum SPL (1m) 140 dB (Preset: VTX G28 80)
System Amplification Crown Audio I-Tech HD
System Impedance 2x 8 ohms
LF Driver (2) JBL 2269H 18-inch Neodymium Differential Drive® woofer
Enclosure Finnish birch plywood, Black DuraFlexTM finish, ten integral recessed handles
Dimensions (H x W x D) 493 mm x 1211 mm x 1211 mm
19.4 in x 47.7 in x 47.7 in
Net Weight (each) 92.5 kg (204 lb)
