This HDMI 4K 1x4 Splitter use a single HDMI source, accessing to multiple HDMI sinks. It allows one HDMI device to be split easily to four HDMI compatible monitors or projectors. In addition, It can also be placed at the end of a long HDMI cable to regenerate the HDMI signal. The resolution of this HDMI Splitter can be up to 3840x2160/60Hz.
Features
- Support 3D Video Format
- Support High Resolution up to 3840x2160/60Hz
- Support Highest Rate of 6G and TMDS Clock can be up to 600Mhz
- Support 8/10/12 bit deep color
- Support AWG26 HDMI Standard Cable: Inpuut up to 15 Meters, Output up to 15 Meters. (When the Resolution is 4K, Input up to 8 Meters, Output up to 8 Meters.)
- Support One Single HDMI Source, Accessing to Multiple HDMI Sinks, The Source can be DVD Player, A/V Receiver, Set Top Box and ETC
| HDMI Resolution | Up to 3840x2160/60HZ |
| Support Video Format | 8/10/12 bit Deep Color |
| Support Audio Format | DTS-HD/Dolby-trueHD/DTS/Dolby-AC3/DSD |
| Max Bandwidth | 600MHz |
| Max Baud Rate | 6Gbps |
| Input Cable Distance | (1080p Resolution) ≤15m, (4K Resolution) ≤8 AWG26 HDMI Standard Cable |
| Output Cable Distance | (1080p Resolution) ≤15m, (4K Resolution) ≤8 AWG26 HDMI Standard Cable |
| Max Working Current | 650mA |
| Power Adapter Format | Input AC (50HZ, 60HZ) 100V-240V; Output: DC5V/1A |
| Operating Temperature Range | (-15°C to +45°C) |
| Dimension (L x W x H) | 178 x 67 x 23 (mm) |
| Weight | 230g |
