ULTRAGRAPH PRO FBQ6200HD
Professional audio engineers have known for decades that a good EQ makes all the difference in how a performance is perceived. Although multi-band graphic equalizers have been around for a long time, they have changed very little… until now! The ULTRAGRAPH PRO FBQ6200HD takes the graphic equalizer into the realm of high-definiton audio, providing robust features and our proprietary FBQ Feedback Detection System – at a price that makes them a must-have for anyone who records or operates a live sound system.
- Audiophile 31-band stereo graphic equalizer for live and studio applications
- Revolutionary FBQ Feedback Detection system instantly reveals critical frequencies and can also be used as audio analyzer
- Ultra-low noise 4580 operational amplifiers for highest signal integrity
- Dedicated Limiters with gain reduction meters for each channel protect your sound system from overload and distortion
- Pink noise generator provides test signals to adapt your sound system to any room acoustics
- Mono subwoofer output with dedicated level control and adjustable crossover frequency
- Additional sweepable high and low-cut filters for each channel remove unwanted frequencies e.g. floor rumble, hiss etc.
- Highly accurate 8-segment LED input/output metering and input gain controls for easy level setting
- Relay-controlled hard bypass with an auto-bypass function during power failure (fail-safe relay)
- Servo-balanced inputs and outputs with 1/4" TRS and gold-plated XLR connectors
- "Planet Earth" switching power supply for maximum flexibility (100
- - 240 V~), noise-free audio, superior transient response plus low power consumption for energy saving
- 3-Year Warranty Program*
- Designed and engineered in Germany
