The FV-200PP Pre-Amplifier Mixer Panel is the basic operation section of the FV-200 Series Emergency Public Address System
| Power Source | Usable Power Supply Unit: FV-200PS
24 V DC (operating range: 19.5 - 27 V DC), M3 screw terminal |
|---|---|
| Current Consumption | 110 mA |
| Audio Input |
EV: -20 dB*, 600Ω, unbalanced, removable terminal block (2pins) Timer : -20 dB*, 600 Ω,unbalanced,removable terminal block (2 pins) Paging : -60/-20 dB* (selectable), 600 Ω, balanced, removable terminal block (3pins) RF Link : 0 dB*, 600 Ω,unbalanced,removable terminal block (2 pins) MIC/LINE 1 - 4 : -60/-20 dB* (selectable), 600 Ω, balanced, removable terminal block (3pins) AUX 1 - 2 : -20 dB*,10 kΩ, unbalanced, RCA Jack |
| Audio Output | Priority output : 0 dB*, balanced, removable terminal block (3 pins)
BGM output : 0 dB*, balanced, Removable terminal block (3 pins) |
| Control Input |
Timer : No-voltage make contact input, open voltage : 24 V DC, short-circuit current : Under 5 mA, removable terminal block (2 pins) Paging : No-voltage make contact input, open voltage : 24 V DC, short-circuit current : Under 5 mA, removable terminal block (2 pins) EV : No-voltage make contact input, open voltage : 24 V DC, short-circuit current : Under 5 mA, removable terminal block (2 pins) |
| Control Output | All Call : Contact Switch (Normally Open), removable terminal block (2 pins) |
| Frequency Response | 50 Hz - 15 kHz, ±3 dB, 1 kHz |
| Muting | MIC/LINE 1 : Mutes other input signals (Mic/Line 2 - 4, AUX 1 - 2) by 0 - 30 dB attenuation |
| Phantom Power | MIC/LINE 1 (selectable) (+21 V DC) |
| Priority Control | Fireman's microphone > EV > Timer > Paging > Remote microphone > Mic / Line 1 > Mic / Line 2 - 4 & AUX 1 - 2 |
| Tone Control |
Bass : -10 dB at 100 Hz, +10 dB at 100 Hz (for INPUT BGM) Treble : -10 dB at 10 kHz, +10 dB at 10 kHz (for INPUT BGM) |
| S/N Ratio | Over 60 dB |
| Distortion | Under 1% (1 kHz, rated output) |
| LED Indicator | Power (Green) |
| Operating Temperature | 0 ℃ to +40 ℃ |
| Operating Humidity | Under 90% RH (no condensation) |
| Finish | Front Panel : Aluminum, black, alumite |
| Dimensions | 482 (W) × 88.4 (H) × 353.3 (D) mm |
| Weight | 4.2 kg |
| Accessory | Removable terminal plug (2 pins) x 7, removable terminal plug (3 pins) x 8, Instruction Manual x 1 |
