DAS ELEVEN SOUND Series 800 Watts RMS, Rotatable 90º x 50º Horn, Dual 12" 2-Way Fullrange Pasive Loudspeaker

ES-212.95

DAS

Whatsapp for enquiry Email for enquiry






ES-212.95

2-Way Passive Point Source
3200W | 141dB |63 Hz-18 kHz | 90º x 50º

The ES-212.95 is a high efficiency and low distortion full range (down to 63Hz) system designed for medium to large-scale installations, specifically for venues with low ceiling heights.

The components of the ES-212.95 are symmetrically arranged to generate an uniform dispersion pattern, using 2 x 12″ LF drivers and 1 x M78N (3”VCD) the ES-212.95 offers tightly controlled coverage patterns (90º x 50º) and high output capabilities being usable individually, or in multiple unit arrays.

The cabinet is designed using top grade birch plywood and protected with an impact resistant ISO-flex paint. The front elements of the cabinet are protected using a solid metal grill assisted by an acoustically transparent fabric.



Frequency Range (-10 dB) 63 Hz – 18 kHz
Horizontal Coverage (-6 dB) 90º
Vertical Coverage (-6dB) 50º
Nominal Impedance 16 ohms
RMS Power Handling 800 W
Maximum Peak SPL at 1m 141 dB

ENCLOSURE

Enclosure Construction Birch Plywood
Enclosure Geometry Trapezoidal
Rigging M10 Rigging Points
Finish ISO-flex Paint
Color Black
Net Weight 39 Kg (85,8 lb)
Dimensions (H x W x D) 370 x 710 x 655 mm
14,6 x 28 x 25,7 in
