This system is designed for small- and mid-sized venues. The vertical dispersion selection by means of the system-integrated filter (30º/45º) makes it possible to control the system’s dispersion lobe in the vertical plane and thus reduce the reverb, improving intelligibility in spaces such as cultural centers, museums, conference rooms…all while delivering superb music reproduction.
The aluminum structure and the IP-66 kit make it a highly reliable and resistant choice, available in any RAL color.
| Performance | |
| Frequency Range (-10 dB) | 150 Hz – 20 kHz |
| Horizontal Coverage (-6 dB) | 120º |
| Vertical Coverage | Switchable: 45º – 30º |
| Nominal Impedance | 4 ohms |
| Transformer Taps 70 V | 7.5 W – 15 W – 25 W |
| Transformer Taps 100 V | 15 W – 30 W – 50 W |
| RMS Power Handling | 80 W |
| Peak Power Handling | 320 W |
| On-axis Sensitivity 1W/1 m | 93 dB SPL |
| Maximum Peak SPL at 1 m | 118 dB SPL |
| Recommended Amplifier | INTEGRAL-A1002 |
| INTEGRAL-A1004 | |
| Recommended Processor | DSP-226 |
| Connectors | |
| Audio Input Connector | 4-way Phoenix 2.54 mm |
| Enclosure | |
| Enclosure Construction | Aluminum |
| Color | Black |
| IP Rating | IP66 |
| Depth | 125 mm (4,9 in) |
| Dimensions ( H x W x D ) | 355 x 125 x 125 mm |
| 14,0 x 4,9 x 4,9 in | |
| Net Weight | 5,3 kg ( 11,7 lb ) |
