This ultra-compact, low-profile subwoofer is ideal for small- and medium-sized installations. Low frequency clarity and reproduction make this an unbeatable system for delivering outstanding music reproduction. Perfect match for the Q Series tops.
Performance | |
Frequency Range (-10 dB) | 40 Hz – 200 Hz |
Nominal Impedance | 8 Ohms |
RMS Power Handling | 250 W |
Peak Power Handling | 1000 W |
On-axis Sensitivity 1W/1 m | 94 dB SPL |
Maximum Peak SPL at 1 m | 121 dB |
Recommended Amplifier | INTEGRAL-A404 |
INTEGRAL-A1004 | |
Recommended Processor | DSP-226 |
Connectors | |
Audio Input Connector | 1 x speakON NL4 |
Audio Output Connector | 1 x speakON NL4 |
Enclosure | |
Enclosure Construction | Birch Plywood |
Enclosure Geometry | Rectangular |
Finish | ISO-flex Paint |
Color | Black |
Depth | 415 mm (16,3 in) |
Dimensions ( H x W x D ) | 305 x 505 x 415 mm |
12,0 x 19,9 x 16,3 in | |
Net Weight | 16,0 kg ( 35,3 lb ) |
Components | |
LF Driver | 10MG |
