MINKEZ Media Player with USB, AM/FM Tuner, Bluetooth, CD/SD Card Input

MMP-13

minkez

Whatsapp for enquiry Email for enquiry






Provide a combined audio source for the broadcasting system, and manually control the CD, MP3, Bluetooth and radio players

  • Standard cabinet-type CD, MP3 (with USB and SD card interfaces) and radio integrated playback equipment.
  • Provide a combined audio source for the broadcasting system, and manually control the CD, MP3, Bluetooth and radio players.
  • Standard cabinet-type design (1U), black alumina brushed panel, humanized drawing, exquisite craftsmanship, showing a high-grade temperament.
  • Built-in USB interface / SD card slot, CD movement and radio, Bluetooth four audio sources, CD player and MP3 player share one channel output, radio and Bluetooth share one channel output.
  • CD uses high-end suction movement.
  • The radio uses a high-sensitivity radio module; FM and AM (FM/AM) stereo two-band reception is optional and the radio frequency memory can be stored up to 99 bands.
  • With infrared remote control function and can independently control the volume control.


Brand Minkez
Model MMP-13
Frequency Response 20 Hz – 20 K Hz (- 2 dB)
THD <= 0.1 %
Channel Separation 65 dB
Dynamic Range 75 dB
S/N Ratio 85 dB
CD-Audio Output 775 mV
Radio Frequency FM: 87.5 – 108.0 M Hz; AM: 522 – 1620 K Hz
Antenna Input FM: 75 Ohm, Unbalanced; AM: Low impedance round ring antenna
Sensitivity FM: <= 10 uA; AM: <= 100 uA
Band Memory 99
Radio Audio Output 775 mV / 600 Ohm
Power Supply 220 V, 50 Hz
Dimensions 240 x 155 mm
Weight 2.1 kg
