VTX series dual 18" subwoofers employ two 2269H 18" transducers featuring Differential Drive technology with two voice coils, two neodymium magnets and extremely high peak-to peak excursion capabilities to deliver extended very low frequency performance.
The VTX S28 can be suspended or ground-stacked and is cardioid-arrayable in either configuration for improved rear rejection. Compatible with VTX V25 suspension, S28 can be suspended at the top of V25 arrays to extend the effective low frequency line length, providing improved vertical pattern control combined with improved rear rejection when used in cardioid mode.
Alternatively, S28 arrays (cardioid or front-firing) can be suspended beside or behind V25 arrays. For theatrical sound design, S28 can be suspended in the middle of flown V25 arrays to facilitate balcony and floor coverage by allowing improved underbalcony penetration. Larger cardioid configurations are also effective where S28 is suspended or ground-stacked in multiple cardioid blocks, each block consisting of 3 enclosures (2 front-firing, 1 rear-firing).
Features- 2269H Differential Drive®, Dual Neodymium Magnet, Dual Voice Coil, Direct Cooled™ dual 18” transducers
- Reverse-Cardioid Arrayable with convenient front-facing NL4 connector and OEM factory presets for cardioid operation
- Compatible with VTX V25 suspension - S28 can be suspended at the top or in the middle of V25 arrays to extend the effective low frequency line length
- BSS® Audio OmniDriveHD V5 Processing for use with Crown Audio ITechHD or VRack and control via JBL HiQnet Performance Manager™
- Companion subwoofer for VTX V20 or VTX V25-II
| System Type | Full Size Suspendable, Cardioid-Arrayable, Dual 18" Subwoofer with Ultra Long Excursion Transducers |
| Frequency Range (-10dB) | 29 Hz - 90 Hz (Preset: VTX S28 80) |
| Coverage | Omnidirectional or Cardioid |
| Maximum Peak Output | 139dB (Preset: VTX S28 80) |
| System Amplification | Crown Audio I-Tech HD |
| System Impedance | 2x 8 ohms |
| LF Driver | (2) JBL 2269H 18-inch Neodymium Differential Drive® woofer |
| Enclosure | Finnish birch plywood, Black DuraFlex finish, ten integral recessed handles |
| Inter-Enclosure Angles | 0, 1, 2, 3, 4, 5, 6, 7, 8, 9, 10 |
| Dimensions (H x W x D) | 493 mm x 1222 mm x 926 mm |
| 19.4 in x 48.1 in x 36.5 in | |
| Net Weight (each) | 83.0 kg (183 lb) |
