This 60W Ultra-thin Digital Mixer Amplifier of MP9306D can be called digital audio amp or mixer amplifier with Bluetooth.
Features
- Built-in digital amplifier module, high efficiency (85%)
- Support Bluetooth and USB
- 2 AUX & 2 Mic inputs & 1 AUX output for power extension
- Each AUX & Mic input with individual volume control
- Mic 1 of 6.35mm in front panel, with priority & muting
- With priority input and 100V input
- Support both AC power and DC 24V power input
- 100V speaker output for long distance transfer
|
Model |
MP9306D |
MP9312D |
|
|
Rated Power |
60W |
120W |
|
|
Speaker Output |
100V |
||
|
Sensibility |
MIC 1 |
0.005（±1mV） |
|
|
MIC 2 |
0.006（±1mV） |
||
|
Line, Priority in |
0.3（±20mV)VRMS |
||
|
Priority in 100V |
100 VRMS |
||
|
SNR |
MIC, Line 1 |
≥74db(Maximum) |
|
|
Line 2, Priority in |
≥80dB（Maximum） |
||
|
Frequency Response |
80Hz-15kHz（±3dB） |
||
|
Distortion |
≤0.5 % |
||
|
Power Supply |
DC24V, AC180-250V/50-60Hz |
||
|
Tone |
Bass |
±10dB （100Hz） |
|
|
Treble |
±10dB （100Hz） |
||
|
Power Consumption |
180W |
90W |
|
|
Packing Size（W×H×L） |
310×275×120mm |
||
|
Product Size（W×H×L） |
200×190×44mm |
||
|
Net Weight |
1.5kg |
||
|
Gross Weight |
2kg |
||
