The KEC-90M is a high quality analog microphone audio cable for high application demand. The PVC outer jacket meets the demand for the most demanding enviroment with special characteristics; high tensile strength and resistance to abrasion.
The cable is suited for the most adverse condition in wet and humid enviroment.
Product Features:
- Balanced Single Pair Microphone Cable
- Robust PVC Jacket
- Ideal for Extension Cable
- Different Color Jacket for Selection
- High Quality Oxygen free Copper Conductor
| Conductor Material: | Stranded Oxygen Free Copper |
| Conductor Description: | 20 x 0.10mm |
| Number of Pairs: | 1 |
| Insulation: | PE (Polyethylene) |
| Cover: | Cotton Yarn, Cotton Paper |
| Shielding Material: | Stranded Oxygen Free Copper |
| Shielding Description: | 96 x 0.10mm |
| Jacket: | PVC (Polyvinyl Chloride) |
| Overall Diameter: | 6.0mm |
| Resistance: | 88.9 Ohm/Km |
| Conductivity: | 98% |
| Max. Pulling Tension: | 5 Kg |
| Current Rating (Max): | 9 Amps |
| Spool Size: | 20 x 14.2cm |
| Cable Spool Length: | 90 Meters |
