SENNHEISER XS Wireless 2 Series Vocal Set with e 835 Characteristics

XSW 2-835

SENNHEISER

Whatsapp for enquiry Email for enquiry






Raise your voice. High flexibility for those willing to go a step further. XS WIRELESS 2 grows with your demands by offering an intuitive LCD display for more manual options and 12 compatible channels in a stable UHF band, withstanding tougher live stage conditions. The XS WIRELESS 2 VOCAL SET is an easy to use all-in-one wireless system for singers and presenters featuring Sennheiser’s renowned evolution microphone capsule e835 (superior dynamic, cardioid) to perform under pressure. True Diversity receiver in a metal housing and rackmount kit included.

  • Excellent live sound featuring Sennheiser’s renowned evolution microphone capsules

  • True diversity receiver with metal housing

  • External antennas

  • Automatic frequency management and synchronization via

  • remote channel for easy setup

  • Fully tunable over a wide range of UHF frequencies

  • Rackmount kit included

  • Up to 12 compatible channels

As easy as analog gets

As easy as analog gets

XS Wireless; the entry-point to our analog portfolio and the first wireless system you’ll ever want to own. We developed XS Wireless 2 for those that want more flexibility without the burden of a complex set-up. Simply turn the system on and let the Automatic Frequency Management do the rest. In optimal environments, you can operate up to 12 wireless connections simultaneously, all without having to search for frequencies or worry about interference.


XSW 1 vs. XSW 2

XSW 1 vs. XSW 2

XS Wireless 1 was developed for those that want to concentrate on the show and not so much on the gear. While XS Wireless 2 shares that same philosophy, we’ve added more control to help you dial in your set-up. Starting with the face of the receiver itself, XS Wireless 2 features a well-designed LCD screen that gives you manual control of your frequency tuning and includes an RF meter that indicates your signal strength. Add a pair of external antennas for increased range as well as two more channels for a total of 12 and its easy to see why XSW 2 is the next step up.


What makes the e835 capsule so special?

What makes the e835 capsule so special?

While every capsule part of the Evolution Series is designed with clarity and presence in mind, not all capsules are created equal. Simply put, the 835 is for vocalists that want a little more help cutting through the mix. Featuring a gentle boost at 3kHz – 5kHz to help with vocal presence, and then enhanced frequencies up to 12kHz for added brightness, the 835 helps your voice shine right out of the box.

What's in the Box
  • 1 receiver EM-XSW 2
  • 1 handheld transmitter SKM 835-XSW
  • 1 microphone clamp MZQ 1
  • 1 power supply NT 12-5 CW
  • 2 AA batteries
  • 1 rackmount kit
  • 1 pouch
  • user manual


Receivers
  • Dimensions
    approx. 200 x 42 x 127 mm, microphone: approx. 260 x 50 mm
  •
  • Weight
    approx. 680g
  •
  • Power supply
    12 V DC nom. / 300 mA
  •
  • Housing
    Metal, microphone: robust ABS
  •
  • AF frequency response
    50 to 16,000 Hz (–3 dB)
  • Microphone
    dynamic
  •
  • Frequency response
    50 to 16,000 Hz (–3 dB)
  •
  • THD, total harmonic distortion
    ≤ 0.9%
  •
  • Pick-up pattern
    cardioid
  •
  • Signal-to-noise ratio
    ≥ 103 dBA
  •
  • RF output power
    10 mW
  •
  • Switching bandwidth
    up to 24 MHz
  •
  • Operating time
    approx. 10 hrs
  •
  • Modulation
    wideband FM
  •
  • Output voltage
    1/4“ (6.3 mm) jack socket (unbalanced): +6 dBu, XLR socket (balanced): +12 dBu
  •
  • Frequency
    8 frequency banks, each with up to 12 factory-preset channels
  •
  • Frequency range
    A: 548-572 MHz
    GB: 606-630 MHz
    B: 614-638 MHz
    C: 766-790 MHz
    D: 794-806 MHz
    E: 821-832 MHz, 863-865 MHz
    K: 925-937.5 MHz
  •
  • Sensitivity
    < 3 μV at 52 dB(A)rms S/N
  •
  • Squelch
    switchable from 3 dBμV to 28 dBμV (via Pilot Tone)
  •
  • Synchronization
    2.4 GHz, Low Power OQPSK (only active during synchronization)
  •
  • Line
    20 dB, switchable
  •
  • Input sensitivity
    1.5 mV / Pa
  •
  • Adjustment Range Transmitter
    0 to -30 dB, adjustable in 10 dB steps
  •
  • Audio adjustment range
    40 dB, adjustable in 5-dB steps
  •
  • Temperature Range
    operation: 0°C to +40°C
    storage: –20°C to +70°C
  •
  • Receiver Principle
    double superheterodyne
  •
  • Diversity principle
    True Diversity
Microphone
  • Weight
    approx. 245g
  •
  • Power supply
    2 AA size batteries, 1.5 V
  •
  • AF frequency response
    80-14,000 Hz
