- 4 channels microphone and 2 line inputs, treble and bass can be controlled separately.
- 6 channels partition output, and partition volume independent control
- Built-in chime, chime options: 4 tonnes and 2 tonnes, with alarm generator
- MP3 decoding module supports USB/SD/BLUETOOTH/FM Radio playback function. With the MP3 remote control, support power-off memory function, MIC recording function
- When the alarm generator starts, background music will audio closed and 6 partition output will automatically open to the maximum output volume
- Built-in 24V DC power input
- Mic 1 to 4 with built-in phantom power supply and switch can be independently controlled
- Audio input with independent control on tone control and total volume control
- A variety of indicator lights (signal, the top of the roof to protect the LED indicator)
- Using fan forcible cooling structure which allowing the machine to work for a long time with a long life span
- There are 5 priority functions:
- (1) First Level EMC Priority: when input the EMC alarm signal, all the sound sources will be turned off and the 6 channels partition output will automatically open.
- (2) Second Level: tel/rem microphone override MIC1 to MIC4, Line1 and Line2, and bell tone.
- (3) Third Level: built-in alarm generator override bell sound, MIC1 to MIC4, Line1 and Line2, 6 partitions output will automatically open.
- (4) Fourth Level: built-in bell tone override MIC1 to MIC4, Line1 and Line2.
- (5) Fifth Level: build-in MIC1 override MIC2 to MIC4, Line1 and Line2.
- Constant voltage output: 70 V, 100 V, rated resistance output: 4 to 16 Ω
| Brand | Minkez |
| Model | MA-500V6Z |
| Pre Amp Out (MIC1 – MIC4, Line1 and Line2, Tel In, Remote In) | 1 V / 600 Ohm |
| Remote MIC Sensitivity / Impedance | 775 mV / 10 K Ohm |
| THD | Less than 0.1 % at 1 K Hz, 1/3 rated power |
| Power Supply | 110V / 60 Hz or 230 V / 50 Hz and DC 24 V |
| Power Consumption | 750 W |
| Dimensions | 484 x 310 x 88 mm |
| Weight | 8.9 kg |
